    CE CCC 12.5A 150 Watt LED Driver DC12V LED Sign Power Supply

    Ask Lasest Price
    Brand Name : HX
    Model Number : HXF-60GB-12
    Certification : CE, CCC, ISO9001:2015
    Price : 1-10USD
    Payment Terms : T/T
    Supply Ability : 8 Production lines, 20000PCS each day
    Delivery Time : Regular stock for ready delivery with our brand
    • Product Details
    • Company Profile

    CE CCC 12.5A 150 Watt LED Driver DC12V LED Sign Power Supply


    Item Name:


    LED light driver 12V 12.5A LED driver, AC/DC 12V 150W LED Power supply, without fan, unique design power supply


    1). Basic Sepcifications

    ModelSize/mmInputOutputOutput CurrentWarranty
    HXF-150GB-12185×73×41AC 180~264VDC 12V12.5A3 Years

    2). Technical Characteristics


    ModelHXF-150GB
    12V
    OutputDC Voltage12V
    Current Range0-12.5A
    Ripper and Noise200mVp-p
    Volt. Accuracy12V±5%,
    Linear regulation±0.3%
    Load regulation±0.5%
    InputAC Voltage range180~264VAC
    PC Factor Typ0.6
    Efficiency Typ≥86%
    AC Current (180VAC)2.5A
    AC Current (240VAC)3.0A
    Inrush CurrentCold start 80A/240V AC
    Leakage Current<3.5mA/240VAC
    Over-load110%-130% of rated power
    ProtectionsShort circuitProtection mode: auto recovery after short circuit faults removed
    Over-voltage <15V >29V
    Protection mode: shot off output voltage, restart to recovery
    EnvironmentWork Temp.-25~40℃
    Work Humidity20%-90% RH no condensation
    Storage Temp.-25~80℃
    Vibration resistancerevolution 280±10%, 45 mins,X.Y.Z three directions
    Drop test800mm
    SurgeCommon mode 4KV, different mode 2KV
    Safety and EMCSafety standardDesign by standard:GB9254-1998,GB17625.1-2003,
    Withstand voltageI/P-O/P 2KVAC I/P-FG 2KVAC O/P-FG 500VAC
    Insulation resistanceI/P-O/P .I/P-FG .O/P-FG: >100MΩ/500VDC/25℃/70%RH
    EMCDesign by standard: EN55022B, Class B
    Harmonic currentDesign by standard:GB17625.1; EN61000-3-2, -3 limitation requirement.
    ImmunityDesign by standard: EN55024; EN61000-4-2,3,4,5,6,8,11
    MTBF≥30000 hours 40℃
    OthersProduct size185×73×41mm
    Net Weight320g
    Packing (pcs/ctn)56PCS

    3). Load and Environment Temperature



    4) Structurer:

    12v led driver


    5) Production capacity and quality control


    Our capacityBuilt in 2004, 17 Years experience,
    10,000 square meters factory, 400+ employees,
    8 production lines, 20000pcs/day
    ISO9001:2015 Quality Management System Certified, 7S administration
    50+ Engineer teams, innovative and independent R&D ability
    EMC lab, SMT plant, Advanced machines and test equipment
    Drop test, high-low temperature test, Salt spray test, surge resistance test, Ageing test,Functional test, MTBF test etc.
